NVIDIA TITAN RTX Ada – New images confirm work on a high-end 4-slot graphics card

GeForce RTX 4090 is distinguished not only by its phenomenal performance, but also by its huge dimensions. After all, there is no doubt that a system with such great computing power requires above average cooling. The only problem is that NVIDIA hasn’t said the last word yet, and there are more and more indications that a more powerful unit with more cooling is on the way. More pictures have hit the net to confirm that something must be in the works.

It’s a pity that we don’t see the entire graphics card, although it can be assumed that the whole thing looks like Moore’s Law was presented to us last December.

NVIDIA TITAN RTX Ada - New images confirm work on a high-end 4-slot graphics card [3]

NVIDIA TITAN RTX Ada – this is what a prototype of a 4-slot graphics card with two 16-pin power connectors looks like

Twitter user @Zed__Wang aka MEGAsizeGPU shared more images confirming the 4-slot design of NVIDIA’s upcoming high-end graphics card. As you can see, the new unit’s honk is to have a special hole through which hot air escapes, as well as four vertically stacked video connectors (1x HDMI and 3x DisplayPort). Everything is based on the AD102-450 core with 18176 CUDA modules and a PCB with the designation PG137-SKU0. It’s a pity that we don’t see the entire graphics card, although it can be assumed that the whole thing looks like Moore’s Law was presented to us last December.

NVIDIA TITAN RTX Ada - New images confirm work on a high-end 4-slot graphics card [1]

NVIDIA TITAN RTX / RTX 4090 Ti Graphics Card NVIDIA GeForce RTX 4090 NVIDIA GeForce RTX 4080 NVIDIA GeForce RTX 4070 Ti graphics card
building Ada Ada Ada Ada
Planning AD 102 – 450 M 102 – 300 AD 103 – 300 AD 104-400
Lithography TSMC “4N” TSMC “4N” TSMC “4N” TSMC “4N”
number of transistors ? 76.3 billion 45.9 billion 35.8 billion
Surface ? 608 mm² 378.6 mm² 294.5 mm²
SM blocks 142 128 76 60
SP units 18176 16384 9728 7680
FP32 Force ? 82.6 TFLOPS 49 TFLOPS 40 TFLOPS
RT cores ? 128 RT third generation 76 RT third generation 60 RT third generation
Tensioner cores ? 512 Generation 4 Motor 304 from the 4th generation Tensor 240 of the fourth generation
L2 cache ? 96 MB 64 MB 48 MB
base clock ? 2230MHz 2210MHz 2310MHz
GPU speed ? 2520MHz 2505MHz 2610MHz
VRAM throughput 24 Gbps 21 Gbps 22.4 Gbps 21 Gbps
VRAM 48 GB GDDR6X 24 GB GDDR6X 16GB GDDR6X 12 GB GDDR6X
memory bus 384 bits 384 bits 256 bits 192 bits
PCIe compliant PCIe 4.0 x16 slot PCIe 4.0 x16 slot PCIe 4.0 x16 slot PCIe 4.0 x16 slot
TDP (basic) ? 450 watts 320 watts 285 watts
TDP (Max) 800 watts (?) 600 watts 516 watts 366 watts
The price is in Polish zlotys ? 9699 Polish zlotys PLN 7,049.00 PLN PLN 4,399.00 PLN
the first show ? October 12, 2022 November 16, 2022 January 5, 2023

NVIDIA GeForce RTX 4090 – Ada Lovelace’s top graphics card tested in eGPU station with Thunderbolt 4

It is still not known what the new flagship card from NVIDIA will be called, although it seems that it will be TITAN RTX Ada or GeForce RTX 4090 Ti (golden cooling elements, rather, indicate the first designation). There will also be 48GB of 384-bit (24Gb/s) GDDR6X memory on board, and the maximum TDP factor is said to be up to 800W. Only the release date of this card remains the biggest mystery. So far, there is no indication that it will start soon, but reports about it have been reaching us for several months now. So we have to wait for more leaks.

NVIDIA TITAN RTX Ada - New images confirm work on a high-end 4-slot graphics card [2]

NVIDIA TITAN RTX Ada - New images confirm work on a high-end 4-slot graphics card [4]

Source: VideoCardz, MEGAsizeGPU, Moore’s Law is Dead
